Product Features

• Excellent Air Distribution
The air can be distributed evenly to every corner of the room through ducting, enabling cooling/heating of multiple areas with one fan coil unit.

• 4 Available Fan Speed*
Each speed offers different external static pressure and air flow which enhances flexibility.
*Only available for FUD20/25B

• High Airflow Range
Airflow ranges from 2,500 CFM to 4,600 CFM.

• Convertible Air Throw Direction*
Convertible discharge air direction (vertical or horizontal air throw) provides flexibility in installation at site.
*Only available for FUD30/40B

• High External Static Pressure (ESP) Range
Availability of up to 230Pa ESP for high static application (without filter for FUD30/40B).

• Cabinet Construction
The enclosure is made from weather-proofed electro galvanized mild steel and coated with epoxy polyester powder layer for protection against severe conditions. Service panel is also available for ease of servicing.

• Left/Right Piping Option
For flexible installation and application at site.

• Fire-Resistant
Polyethylene (PE) insulation is used at every possible condensate panel to prevent all forms of water or moisture penetration. Polyethylene, which is also a type of Closed Cell Foam (CCF) insulation has the following advantages:
– Durable external surface that is resilient to tough dirt.
– Higher degree of puncture resistance when compared to fiberglass.
– Easily cleaned surface (if necessary) to further resist microbial growth.

• Changeable Drive Package*
Non-standard external static pressure and airflow requirements can be sized accordingly at site by changing the factory fitted drive package.
*Only available for belt driven FUD30/40B

• Easy to Service
For models FUD20/25B, there is a service way allocated at the bottom for servicing.

• Female Adaptor (Threaded)
The units come with threaded female adaptor, making installation at site easy by eliminating the brazing process.
